%u00aeSHFW-WX-3837Twin Front Wall Extension(5/23/11)Dimension Tolerances+ 0 / -3/8-inch32%u201dw x 24%u201dhReinforcement37-1/2%u201d38%u201d24%u201d50-1/4%u201d34%u201dw x 10%u201dhReinforcement34%u201dw x 10%u201dhReinforcementRight (Seat) Wall Left (Control) Wall38%u201dControl Area8%u201dw x 30%u201dh Reinforcement7-1/2%u201d1-1/4%u201dBack Wall1-1/4%u201d37%u201d 38%u201d Frame Pocket2%u201d WallReveal%u00aeSHFW-WX-3837Twin Front Wall Extension(5/23/11)Dimension Tolerances+ 0 / -3/8-inch32%u201dw x 24%u201dhReinforcement37-1/2%u201d38%u201d24%u201d50-1/4%u201d34%u201dw x 10%u201dhReinforcement34%u201dw x 10%u201dhReinforcementSeat Wall Control Side Wall38%u201dControl Area1-1/4%u201d Back Wall1-1/4%u201d37%u201d 38%u201d Frame Pocket2%u201d WallRevealPackage Order No.:%u0009 FHV-RS or LS (RS shown) (Fair Housing wall reinforcement)Package Includes: Factory applied, ActivLife, HUD-FHA compliant (Fair Housing), structurally reinforced wall areas (as shown) for independent field application of bars and seat.NOTE: %u201cRS or LS%u201d designates RH or LH reinforced seat wall.%u00ae Package Order No.:%u0009 FH-RS or LS (RS shown) (Fair Housing wall reinforcement)Package Includes: Factory applied, ActivLife, HUD-FHA compliant (Fair Housing), structurally reinforced wall areas (as shown) for independent field application of bars and seat.NOTE: %u201cRS or LS%u201d designates RH or LH reinforced seat wall.ActivLifesolutionsActivLifesolutions103
